Laptop Mother Boards HD Photos

Acer Nitro AN515-34 AN515-43 FH50Q LA-J621P DIS photo HD



FLV34 LA-K051P REV 1B HD Photos
BIOS AND SCHEMATIC

https://pkbiosfix.com/threads/thinkbook-14-g2-itl-laptop-type-20vd-la-k051p-bios-bin.5265/#post-9277



NM-A181 REV 1.0
hd photos



GOG20 LA-L171P Rev.1A (Lenovo IdeaPad Gaming 3-15ACH6) HD Photos



Scanned LA-H501P Rev. 1A board



Scanned LA-H329P Rev.2.0 board

I'm still collecting information for HP 250 G8 boards

This is for now:
HP 250 G8, HP 15-dw, 15s-du,15s-dr ------ LA-H323P Rev.1.0 ( "i" 8-th & 10-th gen. DIS & UMA)
HP 250 G8, HP 15-dw, 15s-du,15s-dr ------ LA-H325P Rev.1.0 ("N" CPU, DIS & UMA)
HP 250 G8, HP 15-dw, 15s-du,15s-dr ------ LA-H329P Rev.1.0 ("i" CPU 10th gen. only UMA)



Scanned NM-B191 Re. 1.0 board



Scanned NM-C711 Rev:1.0 board

Same boards

Lenovo IdeaPad S145-15IWL ------- NM-C121 (Intel "i" 8th gen. DIS & UMA)
Lenovo IdeaPad V15-IIL --------------- NM-C711 (Intel "i" 10th gen. UMA)
Lenovo IdeaPad 15IIL05 -------------- NM-D031 (Intel "i" 10th gen. DIS & UMA)



HD photos for LA-H101P REV:1.0
S340-15IWL Touch



Scanned LA-L241P Rev. 1.0 board

The Board can go into:

Acer Nitro AN515-52
Acer Nitro AN515-53



HD photos for AITE1 NM-A221 (REV 1.0)



HD photos for HP 6470B 8470P 6050A2466401-MB-A03_UMA



HD Photos
FPC52 LA-H461P



Scanned NM-B453 Rev: 1.0 board

Same shape of board also:

320-15IKB,17IKB -------------- NM-B451 (Intel "i" 8th gen. only UMA)
330-15IKB ------------------------ NM-B452 (Intel "i" 8th gen. DIS)
330-15IKB ------------------------ NM-B453 (Intel "i" 8th gen. DIS)
320-15ISK 520-15ISK ------- NM-B241 (Intel "i" 6th 7th gen. only UMA)
320-15ISK 520-15ISK ------- NM-B242 (Intel "i" 6th gen. DIS)
330-15IGM ----------------------- NM-B661 ("N" CPU) Socket: FCBGA1090
320-15IAP ----------------------- NM-B301 ("N" CPU) Socket: FCBGA1296
320-15ACL ----------------------- NM-B321 (AMD E2/A4/A6/A9 CPU DIS & UMA)



Scanned LA-B092P board

Same shape of board also:
List is incomplete for now..

B50-30 LA-B101P Rev:1A ("N" CPU with GPU)
B50-30 LA-B102P Rev:1A ("N" CPU without GPU)
B50-70 LA-B091P Rev:3.0 ( "i" CPU 4th-5th gen. with GPU)
B50-70 LA-B092P Rev:1.0 ( "i" CPU 4th gen. without GPU)
B51-30 LA-C292P Rev:1.0 ( "N" CPU without GPU)



Scanned DA0ZAVMB8G0 REV.G board

Same shape of board also:

Acer A315-21 ---- DA0ZASMB8D0 Rev.B (AMD with & without GPU)
Acer A315-31 ---- DA0Z8PMB8D0 REV.D ( "N" CPU with onboard RAM without GPU)
Acer A315-51 ---- DA0ZAVMB8G0 Rev.G ("i" CPU with 6th, 7th, 8th gen. without GPU)



Scanned NM-C361 Rev: 1.0 board ("i" 9th gen. with GPU)



Scanned LA-H323P Rev.1.0 board

I'm still collecting information for HP 250 G8 boards

This is for now:
HP 250 G8, HP 15-dw, 15s-du,15s-dr ------ LA-H323P Rev.1.0 ( "i" 8-th & 10-th gen. DIS & UMA)
HP 250 G8, HP 15-dw, 15s-du,15s-dr ------ LA-H325P Rev.1.0 ("N" CPU, DIS & UMA)
HP 250 G8, HP 15-dw, 15s-du,15s-dr ------ LA-H329P Rev.1.0 ("i" CPU 10th gen. only UMA)


If you have information to add boards for this list, send me a message.
I will gladly add.



Scanned Photos of LA-D711P Rev.3.0
(Scanner is HP Scanjet G3010)

Btw... this is the all board for HP 250 G4

HP 250 G4 G5, HP 15AC, 15BA, 15AF, 15AY ------- LA-C701P ("i" CPU 5th gen. with & without GPU)
HP 250 G4 G5, HP 15AC, 15BA, 15AF, 15AY ------- LA-C811P ("N" CPU without GPU)
HP 250 G4 G5, HP 15AC, 15BA, 15AF, 15AY ------- LA-C781P (AMD with & without GPU)
HP 250 G4 G5, HP 15AC, 15BA, 15AF, 15AY ------- LA-D711P (AMD with & without GPU)
HP 250 G4 G5, HP 15AC, 15BA, 15AF, 15AY ------- LA-D702P ("N" CPU with & without GPU)
HP 250 G4 G5, HP 15AC, 15BA, 15AF, 15AY ------- LA-D703P ("i" CPU 5th gen. with & without GPU)
HP 250 G4 G5, HP 15AC, 15BA, 15AF, 15AY ------- LA-D704P ("i" CPU 6th gen. with & without GPU) DDR4
HP 250 G4 G5, HP 15AC, 15BA, 15AF, 15AY ------- LA-D707P ("i" CPU 7th gen. with & without GPU) DDR4



Scanned LA-F761P Rev.1.0 board

Btw... this is the all board for HP 250 G6

HP 250 G6, HP 15-bs, 15-bw ------ LA-F761P (Intel "i" 5gen. CPU) Socket: FCBGA1168
HP 250 G6, HP 15-bs, 15-bw ------ LA-E791P (Intel "i" 6gen. 7gen. CPU) Socket: FCBGA1356
HP 250 G6, HP 15-bs, 15-bw ------ LA-E801P (Intel "i" 7gen. CPU) Socket: FCBGA1356
HP 250 G6, HP 15-bs, 15-bw ------ LA-E802P (Intel "i" 7gen. 8gen. CPU) Socket: FCBGA1356
HP 250 G6, HP 15-bs, 15-bw ------ LA-E821P ("N" CPU) Socket: FCBGA1296
HP 250 G6, HP 15-bs, 15-bw ------ LA-E811P ("N" CPU) Socket: FCBGA1170
HP 250 G6, HP 15-bs, 15-bw ------ LA-G121P ("N" CPU) Socket: FCBGA1090
HP 250 G6, HP 15-bs, 15-bw ------ LA-E841P (AMD CPU)



Scanned Photos of LA-G07JP Rev.2.0

Btw... this is the all board for HP 250 G7

HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G07JP (AMD CPU)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G078 (AMD CPU)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G073P ("N" CPU FCBGA1090)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G074P ("N" CPU FCBGA1170)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G07FP ("I" 8th with & without GPU)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G07DP ("I" 7th with & without GPU)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-J951P ("I" 10th without GPU)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-J952P ("I" 10th with GPU)



Scanned photos of LA-J952P board

Btw... this is the all board for HP 250 G7

HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G07JP (AMD CPU)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G078 (AMD CPU)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G073P ("N" CPU FCBGA1090)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G074P ("N" CPU FCBGA1170)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G07FP ("I" 8th with & without GPU)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-G07DP ("I" 7th with & without GPU)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-J951P ("I" 10th without GPU)
HP 255, 250, 256 G7 HP 15-DB, DA ---- LA-J952P ("I" 10th with GPU)



HD Photos
DA0PADMB8G0 rev G



HD photos for CTL51 53 LA-E841P (REV 2.0)



HD Photos for HP 14-cm0005la 6050A2983401_HAGRID_RevA02_UMA



HD photos for Acer Aspire A515-41G LA-e903P



HD photos for Lenovo Ideapad LA-C771P



HD Photos front and back for LA-C503P ASW50



HD photos for LENOVO V130-15IKB LV315KB_448.0DC04.003M_Rev 17807-3M_DISCRETE



HD photos for HP PROBOOK 350 G1 SNOWI10-6050A2608301-MB-04
