HD PHOTOS NM-C371 Rev.1.0 (Lenovo Legion Y7000) HD Photos

Scanned NM-C371 Rev.1.0 motherboard



Link for Bios, PDF & BRD Schematic

LENOVO Post in thread 'Legion Y7000 FY521/FY522/FY510/FY520 NM-C371 BIOS BIN+SCHEMATIC+BOARDVIEW'

Feb 6, 2023

Legion Y7000 FY521/FY522/FY510/FY520 NM-C371 BIOS BIN
SRF6U (Intel Core i7-9750H)
SRF6U BIOS TESTED BY PKBIOSLAB.
ITE PIN OUT.
NM-C371 KB_pins=32 (JKB1) LEFT DOWN 08MM PD0=2 PD1=11 PD2=16 PD3=8 PD4=17 PD5=15 PD6=19 PD7=1 BUSY=5 STB=13 AFD=3 INIT=10 SLIN=12 KSI4=9 KSI5=7 FLASH=56 IT8176
