HD PHOTOS NM-B241 Rev.1.0 (Lenovo Ideapad 330-15IKB) HD photos

Scanned NM-B241 Rev.1.0 board

Same shape of board also:

320-15IKB,17IKB -------------- NM-B451 (Intel "i" 8th gen. only UMA)
330-15IKB ------------------------ NM-B452 (Intel "i" 8th gen. DIS)
330-15IKB ------------------------ NM-B453 (Intel "i" 8th gen. DIS)
320-15ISK 330-15IKB ------- NM-B241 (Intel "i" 6th 7th gen. only UMA)
320-15ISK 520-15ISK ------- NM-B242 (Intel "i" 6th gen. DIS)
330-15IGM ----------------------- NM-B661 ("N" CPU) Socket: FCBGA1090
320-15IAP ----------------------- NM-B301 ("N" CPU) Socket: FCBGA1296
320-15ACL ----------------------- NM-B321 (AMD E2/A4/A6/A9 CPU DIS & UMA)

BIOS - Lenovo 80XH NM-B241 BIOS BIN+SCHAMATIC+BOARDVIEW

NM-B241 Lenovo 80XH NM-B241 BIOS, ECROM Schematics, boardview NM-B241 R10.tvw OK
