About this board
Files for the Dell Precision 7730 DAP20 motherboard, board number LA-F601P.
Dell had this board built by Compal; Compal board numbers start with LA- and end in P. Check the number printed on the PCB before you download. Board revision: 1.0. Match the revision as well as the board number.
What this thread covers
- BIOS (full SPI chip dump, .bin)
Typical reasons to reflash: no power or no display after a failed BIOS update, a BIOS/supervisor password lock, or a corrupted Intel ME region.
Back up the original dump first — it contains machine-specific data (serial, UUID, MAC, ME), and you will want it if anything goes wrong.
If you have a working file for this board, please share it below. More files: search LA-F601P in File Finder.
Attachments
DELL PRECISION 7730 DAP20 LA-F601P SR3YZ CLEAN ME.rar
10.5 MB · Views: 26
10.5 MB · Views: 26
DELL PRECISION 7730 - DAP20 LA-F601P REV1.0 BoardView.cad.zip
368.2 KB · Views: 16
368.2 KB · Views: 16
COMPAL LA-F601P PDF.pdf
2 MB · Views: 8
2 MB · Views: 8
