INVEENTEC Berlin10ADG 8L 6050A2333101 Toshiba Satellite L650 L650D
Bios Schematic and Boardview
Bios Schematic and Boardview
About this board
This thread is for the Toshiba Satellite L650 L650D INVEENTEC Berlin10ADG 8L with main board 6050A2333101.
The board was manufactured by Inventec for Toshiba. Inventec board numbers start with 6050A, so you can confirm it on the PCB silkscreen.
Files usually needed for this board
- BIOS (full SPI chip dump, .bin)
- EC / KBC firmware, if the board uses a separate EC chip
- Schematic (PDF)
- Boardview (.brd / .bdv / .cad)
Usually needed when the laptop powers on with a black screen after a BIOS update, is stuck in a boot loop, or is locked with a BIOS password.
Before flashing, always read and save the original chip. It holds the serial number, UUID, MAC address and ME data for that exact machine.
Have a tested file for 6050A2333101? Reply below and help the next technician. Looking for something else? Search all files in the File Finder.
